UFO Drip Coffee Bag Packing Machine | Hanging Ear Filler
UFO Drip Coffee Packaging Machine
| Model | ZC-UFO30 |
turnkey solution
The UFO Drip Coffee Packaging Machine is a newly developed all-in-one system designed specifically for the popular UFO-shaped hanging ear (drip) coffee. This machine integrates cup forming, precise coffee powder filling, lid placing, sealing, and outer pouch packing in one compact, energy-efficient unit. Ideal for small- to medium-scale specialty coffee brands, it delivers a production capacity of 20–40 bags per minute, depending on coffee volume.
With a compact footprint and high performance, it is an excellent solution for launching your next-generation coffee packaging line.
description
Main Features：
- One-stop packaging: From forming to filling, sealing, and bagging.
- Production speed: 20–40 cups/min (depending on product weight).
- Space-saving design: Compact and energy-efficient structure.
- International components: Uses trusted global electrical brands for stable performance.
- Easy to use: PLC programmable controller and touchscreen HMI interface.
Working Stations：
S1 – Automatic cup feeding
S2 – Cup detection
S3 – Paper bag forming
S4 – Coffee powder filling
S5 – Plastic lid placing
S6 – Lid pressing
S7 – Lid detection
S8 – Logo paper disc placement
S9 – Logo pressing
S10 – Film forming + nitrogen filling + final bagging
S11 – No-lid rejection
parameter
| ZC Model | ZC-UFO30 |
|---|---|
| Productivity | Stable output: 4200 capsules/hour |
| Cup Size (Diameter × Height) | Ø37–120 mm × H28–50 mm |
| Sealing Film Diameter | Ø37–120 mm |
| Power Supply | Single Phase 220V |
| Main Motor Power | 0.75 KW |
| Total Power | 3 KW |
| Air Pressure | 0.6–0.8 MPa |
| Air Consumption | 0.4 m³/h |
| Noise Level | <70 dB |
| Machine Weight | 1000 kg |
| Automation | Automatic waste rejection, auto-stop on overload |
